FrSky DF 2.4Ghz Combo Pack for JR w/ Module & RX

Reference: AC423

Condition: New product

1 Item Items

Warning: Last items in stock!

More info

FrSky DF 2.4Ghz Combo Pack for JR w/ Module & RX

PLEASE NOTE - see bottom of page below - This item is supplied with RX and TX module that have Telemetry funtionality

FrSKY ACCST technology is proven, approved by many model associations, tested and reviewed as the leading Chinese 2.4Ghz R/C Technology. If you think DSM2 or FASST is the best, think again!

New FrSKY ACCST (Advanced Continuous Channel Shifting Technology) gives you secure radiocommunicationsin

2.4Ghz band. ACCST 2.4GHz system shifts 80 channels around hundred times per second in the 2.4GHz band. This means that the system is completely resistant to interference in that band.

The two-way Radio System developed by FrSky provides an additional return link that would be used for monitoring theRxs voltage, temperature, location, speed and so on.

Features:
Advanced Continuous Channel Shifting Technology (ACCST is our advanced tecnology it shifts channel hundred times per second and there is no signal conflicts and interruptions) robust frequency agility.
Easy to bind and very fast link-up.
Excellent reboot time.
True Diversity with two antennas.
All channels can be programmed with Failsafe, quickly and easily.
Quick and extremely stable in performance.
Precise and smooth servo response.
Extended range (1.5km-2.5km).

FrSky DJTis compatible with JR transmitters following:
JR: 347, 388, 783, U8, PCM10, PCM10S, PCM10SX, PCM10IIS, 8103, J9303, PX, 9X v2, 11XZERO

Receiver Specification:
Operating voltage: 3.5 - 10.0V
Power consumption: 100mA
Resolution: 3072
Latency: 22ms
Analog voltage: 0~3.3V
Number of channels: 8
Range: 1.5km-2.5km
Dimensions:55 x 25 x 14 mm
Weight: 12.4g
Version: 2.0

Module specification:
Operating voltage: 6.0V-13.0V (can handle 3S!)
Power consumption: 50mA
Output Power:: 60mW
Resolution: 3072 (11bit)
Dimensions: 63.9x48.5x36.5mm
Version: 2.0

Included.
1 x 8-channel transmitter module DJT-II (V2)
1 x Transmitter Antenna
1 x 8-channel receiver D8R-II Plus

Download the Manual

Click here for the FrSky DJT User Manual and additional information from our friends at FrSky.

Please note:

if you are intending to use this module with the popular TURNIGY 9x Transmitters or other clones , please check first that the pins in the module compartment are not as shown below - should yours be like the one in the photo then you will be required to remove the back of the TX and cut away some of the plastic surrounding the pins to allow the FrSky module to fully be inserted in the module compartment - see image below
